4G Kategori
LTE CAT.4
Max 4G speed
FDD LTE,TDD-LTE,WCDMA
4G/3G Standartları
4G FDD_LTE:B1/B3/B5/B7/B8/B20
4G TDD-LTE:Band38/Band40
3G WCDMA:B1/B5/B8
Working Bands
DL:150Mbps
UL:50Mbps
Wi-Fi Standartları
802.11b/g/n/ax
Wi-Fi Frekansı
2.4GHz
Wi-Fi Hızı
Wi-Fi6
2.4GHz:286Mbps
Wi-Fi Transmit Power
2.4GHz:up to 20dBm
USB Grişi
USB-C port
SIM Yuvası
Nano SIM slot
SD Kart Yuvası
Reset hole
Buton
Power on/off
Reset hole
Antennas
2 Internal 4G/3G Antennas
1 Internal Wi-Fi Antennas
Indicator
1.44 inches colorful screen
4G/3G Signal bar ,Carrier name,Cellular type,Roam,SMS,Battery meter
Cellular data monitor
Download speed
Wi-Fi and connected No.
Wi-Fi name
Wi-Fi key
Wi-Fi QR Code
Batarya
Type: Li (rechargeable)
Capacity: 3.8V, 2100 mAh,7.98Wh
Working time: up to 8.5hours (depending on the network)
Standby time: up to 168hours (depending on the network)
Yazılım
WAN Tipi
4G/3G
4G/3G Özellikleri
Auto-APN
Auto dial-up
Roaming
SMS(Send/Receive/Delete)
USSD
Data limted
Power save
PIN Management
USB Tethering
Wi-Fi İşlevleri
Broadcast and Hide Wi-Fi name
Scan QR code to connect Wi-Fi
Software features
Local management
DHCP Server
QOS
Upgrade firmware from local or OTA
IPV4/IPV6
Certifications
Certifications
CE Granted
ROHS Granted
IPV6 Host
Working Environment
Temperature
Operating Temperature: 0?~35?
Humidity
Storage Humidity: 5% ~ 90% RH Non-condensing
Package Contents
Package Contents
1 * Mobile Wi-Fi
1 * USB-C cable
1 * Rechargeable Battery
1 * Quick Installation Guide
