Product Dimensions 127×117×160 mm(L×W×H)Heatsink Dimensions 127×92×156
mm(L×W×H)Net Weight 1291 gHeatpipe Ø6 mm×5 pcsFan Dimensions 120
×120×25 mm(L×W×H)Fan Speed 500~1850 RPM±10%Fan Airflow 68.99 CFMFan Air
Pressure 2.19 mmAqFan Noise ?28 dB(A)Fan Speed (with LSP) 500
~1550 RPM±10%Fan Airflow (with LSP) 52.24 CFMFan Air Pressure (with
LSP) 1.2 mmAqFan Noise (with LSP) ?25.9 dB(A)
Fan Connector 4-pin PWMBearing Type Fluid Dynamic BearingFan Rated
Voltage 12 VDCFan Rated Current 0.12 AFan Power Consumption
1.44 WLED Type Addressable RGB LEDLED Connector 3-pin(+5V-
D-G) and 9-pin USB 2.0LED Rated Voltage 5 VDCLED Power Consumption 4.5
WEAN 6933412728276P/N R-AK500-WHADMN-G
